5081
230V three-phase rail projector for indoor use, with adjustable light projection. Aluminum body with the possibility of painting in different colors.
General Information
Application
Indoor
Indoor
General led color
Optional
Optional
Mounting Type
Spotlights & Tracks
Spotlights & Tracks
IK
IK03
IK03
IP
IP20
IP20
CRI
GU10AR111: >80; COB: 90
GU10AR111: >80; COB: 90
UGR
GU10AR111: <29; COB: <19
GU10AR111: <29; COB: <19
Class
I
I
Shape
Circular
Circular
MacAdam
COB: 2
COB: 2
Measures
Ø 115 x 160
Ø 115 x 160
Standards
EN 60598-1;
EN 60598-2-1
EN 60598-1;
EN 60598-2-1
Beam Angle
GU10AR111: 48º; COB: 34º
GU10AR111: 48º; COB: 34º
Directives
RoHS; 2014/35/EU
RoHS; 2014/35/EU
Average Life
GU10AR111: 25000h; COB: 50000h
GU10AR111: 25000h; COB: 50000h
Light Source
Optional
Optional
Light projection
Orientable light projection
Orientable light projection
Electrical Supply
220-240V AC~50/60Hz
220-240V AC~50/60Hz
Energy Efficiency
GU10AR111: G; COB: E
GU10AR111: G; COB: E
